High Purity Vanadium Plate

High Purity Vanadium Plate

High purity vanadium plates are produced by the vanadium raw material - melting - forging - rolling - inspection - shipping, and they are used in military, chemical equipment and medical applications.
Send Inquiry
Product Introduction

1. Product Basic Introduction

High purity vanadium plate is a high melting point rare metal plate and important strategic material, widely used in cutting-edge high-tech, military, mechanical engineering, automotive and aerospace industries. When heated in air, vanadium oxidizes into multiple oxides, and it can react with chlorine at lower temperatures to form vanadium tetrachloride.

Adding vanadium can optimize the microstructure of copper-based alloys and enhance the performance of aluminum alloy pistons. With low fast neutron absorption cross-section, liquid sodium corrosion resistance and high-temperature creep resistance, vanadium can serve as cladding material for fast breeder reactor fuel rods. Its intermetallic compounds have superconducting properties.

2. Product Parameter Table

Item Specification
Product Name High Purity Vanadium Plate
Purity V>99.9%
Dimension Length:50–1500mm, Width:0–300mm, Thickness:3–25mm
Impurity Max(wt%) Si:0.01%; Al:0.01%; Fe:0.015%; Ti:0.001%; Nb:0.001%; W:0.0005%; Cr:0.006%; O:0.015%; N:0.005%; C:0.005%
Other Index Grain size <100μm, free of inclusions and defects
Features High purity, high temperature resistance, corrosion resistance

3. Product Advantages

Stable high purity. Interstitial impurities such as O, N and C are strictly controlled for coating and nuclear research applications.

Excellent high temperature and corrosion resistance, good anti-creep property for high-temperature service.

Uniform grain structure, free of cracks and inclusions, good machinability for further processing.

Wide size range, cutting and custom processing according to drawings available.

Full vanadium product line: vanadium ingot, vanadium wire, vanadium target, large-size vanadium tube etc.

4. Testing & Applications

Testing Methods

Dimensional inspection: Caliper & micrometer to check dimension tolerance

Chemical analysis: ICP for metallic impurities, gas analyzer for O/N/C, MTC certificate provided

Metallographic test: Grain size inspection, internal inclusion & defect detection

Visual inspection: Surface scratches, peeling and oxidation check

Applications

Sputtering target, vacuum evaporation coating, alloy additive, profile deep processing; nuclear research material, chemical catalyst, special glass & ceramic, aerospace material research.

1
2
123

5. Why Choose Yusheng Metal

Yusheng Metal specializes in high purity vanadium rare metal products. We adopt mature rolling and finishing process for vanadium plate, carefully control grain structure and impurity level. Small trial orders and bulk export orders are acceptable with competitive price and stable quality. Custom cutting service is available. Products are packed in moisture-proof wooden cases for export. We track orders till delivery and supply MTC test certificates for each batch.

6. FAQ

Q1: What does purity V>99.9% mean? A1: Vanadium base content exceeds 99.9%. Impurities like Si, Fe, O, N, C are limited within standard thresholds, ideal for coating, alloy and high-end research.

Q2: What are the main applications of vanadium plate? A2: Mainly for sputtering targets, vacuum evaporation coating, alloy additive and custom machined parts for scientific & nuclear related tests.

Q3: Can you customize dimensions? A3: Yes, we can cut plates as required and produce custom length, width and thickness.

Q4: Can you provide MTC material test certificate? A4: Yes, MTC report is available for every batch.

Q5: What other vanadium products do you supply? A5: We supply vanadium ingot, vanadium wire, vanadium target, large-size vanadium tube and other vanadium machined components.



If you want to know more about the product, please feel free to contact us!









Hot Tags: High Purity Vanadium Plate, suppliers, manufacturers, factory, customized, buy, price, quotation, quality, for sale, in stock, Vanadium, High Purity Vanadium Plate, Vanadium Plate, High Purity Vanadium Sheet, Polished Vanadium Plate
